The MU232 product adopts an inertial measurement unit (IMU) with high-precision gyroscopes and accelerometers. It has internal parameter compensation for the full temperature range, outputting the angular velocity and linear acceleration of the carrier, which can maintain high measurement accuracy for a long time. Advanced MEMS technology, structural sealing design and other measures are adopted to ensure the adaptability of the product in harsh environments. This product can replace foreign products of the same performance and supports providing customized services based on users' demands.
Typical applications：
This product can be applied to the measurement, navigation and control of carriers such as vehicles and electro-optical pods.
1. Strong adaptability: Silicon micro MEMS devices have strong resistance to vibration and shock, and can operate at full temperatures ranging from -40℃ to +85℃.
2. High device precision: It adopts a gyroscope with extremely low noise, and the zero bias stability of the gyroscope is ≤ 5 °/h(smooth in 10s).
3. Good user experience: Supports RS-422 interface, adjustable output bandwidth, adjustable output protocol, and online upload of programs/parameters.
4. The maximum output frequency is 2000Hz.
