The IMU86X product adopts an inertial measurement unit (IMU) with domestic gyroscopes and accelerometers. All electronic components used are 100% domestic. The internal parameters are compensated for the full temperature range, and the angular velocity and linear acceleration of the output carrier can maintain high measurement accuracy for a long time. Advanced MEMS technology, structural sealing design and other measures are adopted to ensure the adaptability of the product in harsh environments. This series of products can replace foreign products of the same performance and can also replace medium and low precision fiber optic gyroscopes. It supports providing customized services according to users' demands.
Typical applications：
This product can be applied to the measurement, navigation and control of carriers such as aircraft, vehicles, robots, surface vehicles and electro-optical pods.
1. All components are 100% domestically produced.
2. Small in size and low in power consumption.
3. High bandwidth and low latency.
4.Full temperature standard compensation from -40℃ to +80℃.
5. Resistant to harsh mechanical environments.
6. It has the function of online software upgrade.
7. The maximum output frequency is 4000Hz.
