The MU260 product is an inertial measurement unit (IMU) equipped with high-precision gyroscopes and accelerometers. It adopts high-performance temperature compensation algorithms and inertial device calibration algorithms, capable of outputting the angular velocity and linear acceleration information of the carrier.
The inertial measurement unit integrates all components within a space of 25mm×23.5mm×8.7mm, with an overall weight of less than 15 grams. It is equipped with an RS-422 external interface and features small size, high precision, shock resistance, and good repeatability. The product can replace foreign products of the same performance and supports providing customized services according to users' demands.
Typical applications：
This product can be applied to the measurement, navigation and control of carriers such as vehicles and electro-optical pods.
1. Strong adaptability: Silicon micro MEMS devices have strong resistance to vibration and shock, and can operate at full temperatures ranging from -40℃ to +85℃.
2. High device precision: It adopts a gyroscope with extremely low noise, and the zero bias stability of the gyroscope is ≤ 5 °/h(smooth in 10s).
3. Good user experience: Supports RS-422 interface, adjustable output bandwidth and frequency, adjustable output protocol, and supports online upload of programs/parameters.
4. The maximum output frequency is 2000Hz.
