MA762 MEMS attitude Reference System

The MA762 MEMS attitude reference system product is an attitude and heading reference system (AHRS). The system integrates multiple sensors such as gyroscopes, accelerometers, and attitude systems internally. It adopts self-developed spatial calibration technology to quickly calibrate the magnetic interference that is widely present on user equipment. After successful calibration, It can output high-precision azimuth, pitch, roll Angle, as well as temperature, three-axis magnetic field, three-axis acceleration and other data. In addition, it is equipped with a built-in geomagnetic field model that can automatically calculate the local magnetic declination based on the input longitude, latitude and time information, achieving automatic conversion between magnetic north and true north. It can provide multiple baud rates and different output modes for users to choose from. It features high precision, small size and low power consumption, and can meet users' application requirements such as orientation and pose measurement.
