The S230 product is used to measure the static tilt Angle of the carrier relative to the horizontal plane. By measuring the change in static gravitational acceleration, it converts it into a change in the tilt Angle. This tilt sensor adopts A silicon micro-mechanical sensor and a high-performance microprocessor. Through high-speed and high-precision A/D conversion, it digitizes the tilt analog signal. By using digital filtering methods, it reduces the noise of the measurement signal, enhances the stability of the measurement data, and ensures the real-time performance and accuracy of the measurement. The power interface and communication interface of the product are treated with electromagnetic compatibility. Ensure the reliability of the product. The S230 tilt sensor is available in both single-axis and dual-axis specifications, with measurement ranges of ±15° and ±30° respectively. It supports multiple communication methods such as RS-232, RS-422, RS-485 and TTL. The software interface protocol takes into account both intuitiveness and data security, making it easy for users to operate and use.
1.The silicon micro-mechanical sensor measures the biaxial tilt Angle variation with the horizontal plane as the reference plane.
2.The output Angle is based on the measurement reference surface, which is calibrated at the factory.
3. The tilt Angle variation is output in the form of data, and the interface forms include multiple methods such as RS232, RS485, and RS422.
4. The user resets the output position of the inclination Angle relative to the zero point through the serial port command.
5. The product has a strong ability to resist external electromagnetic interference.
6. The product will not be damaged even when subjected to high-intensity instantaneous impact.
Civilian application field：
a. Pitch Angle measurement of directional satellite communication antennas
b. Application of shield pipe jacking
c.Monitoring of the condition of DAMS, Bridges and towers
d. Engineering vehicle leveling, safety protection for aerial platforms
e. Measurement of ship navigation attitude
f. Tilt detection of geological equipment
